Specifications

  • Manufacturer: Bobcat
  • Model: CT1025
  • Type: Tractors
  • Horsepower: 24.5 hp
  • Lift Capacity At 24" Behind Lift Point: 700 lb
  • Pto Hp: 18.8 hp
  • Transmission Type: Infinite, 2 Range Hydrostatic
  • Width: 46 in
  • Turning Radius: 8' 3"
  • Wheelbase: 4' 7"
  • Emissions Tier (epa): Tier 4
  • Horsepower: 24.5 hp
  • Displacement: 61 in³
  • Number Of Cylinders: 3
  • Gross Hp: 24.5 hp
  • Engine Model: 3c100lfh-u1
  • Operating Weight: 1,521 lb
  • Travel Speed: 11 mph
  • Travel Speed - Reverse: 7.5 mph
  • 3-point Hitch: Category 1
  • 3-pt Lift Control Type: Hydraulic Position Control System
  • Lift Capacity At 24" Behind Lift Point: 700 lb
  • Rear Pto System: Independent
  • Rear Pto - Rpm: 540
  • Pto Hp: 18.8 hp
  • Mid Pto - Rpm: 2200
  • Fuel Tank: 6.7 gal
  • Implement Hydraulic Flow: 4.6 gal/min
  • Total Hydraulic Flow: 6.4 gal/min
  • Steering Hydraulic Flow: 1.8 gal/min
  • Brake Type: We Multi Disc
  • Transmission Type: Infinite, 2 Rangehydrostatic
  • Length: 99.3 in
  • Width: 46 in
  • Height: 87.6 in
  • Ground Clearance: 6.3 in
  • Turning Radius: 8' 3"
  • Wheelbase: 4' 7"
  • Front Tire Size: Front Industrial (ag, Turf) 18x8.5-10 (18x8.5-10,18x8.5-10 )
  • Rear Tire Size: Rear Industrial (ag, Turf) 26x12-12 (26x12-12,26x12-12 )
  • Loader Lift Height: 6' 0"
  • Lift Capacity @ 500mm Ahead Of Bkt Pivot: 702 lb
  • Bucket Width: 4' 0"
