Specifications
- Manufacturer: Bobcat
- Model: CT1025
- Type: Tractors
- Horsepower: 24.5 hp
- Lift Capacity At 24" Behind Lift Point: 700 lb
- Pto Hp: 18.8 hp
- Transmission Type: Infinite, 2 Range Hydrostatic
- Width: 46 in
- Turning Radius: 8' 3"
- Wheelbase: 4' 7"
- Emissions Tier (epa): Tier 4
- Horsepower: 24.5 hp
- Displacement: 61 in³
- Number Of Cylinders: 3
- Gross Hp: 24.5 hp
- Engine Model: 3c100lfh-u1
- Operating Weight: 1,521 lb
- Travel Speed: 11 mph
- Travel Speed - Reverse: 7.5 mph
- 3-point Hitch: Category 1
- 3-pt Lift Control Type: Hydraulic Position Control System
- Lift Capacity At 24" Behind Lift Point: 700 lb
- Rear Pto System: Independent
- Rear Pto - Rpm: 540
- Pto Hp: 18.8 hp
- Mid Pto - Rpm: 2200
- Fuel Tank: 6.7 gal
- Implement Hydraulic Flow: 4.6 gal/min
- Total Hydraulic Flow: 6.4 gal/min
- Steering Hydraulic Flow: 1.8 gal/min
- Brake Type: We Multi Disc
- Transmission Type: Infinite, 2 Rangehydrostatic
- Length: 99.3 in
- Width: 46 in
- Height: 87.6 in
- Ground Clearance: 6.3 in
- Turning Radius: 8' 3"
- Wheelbase: 4' 7"
- Front Tire Size: Front Industrial (ag, Turf) 18x8.5-10 (18x8.5-10,18x8.5-10 )
- Rear Tire Size: Rear Industrial (ag, Turf) 26x12-12 (26x12-12,26x12-12 )
- Loader Lift Height: 6' 0"
- Lift Capacity @ 500mm Ahead Of Bkt Pivot: 702 lb
- Bucket Width: 4' 0"
