Specifications
- Manufacturer: Bobcat
- Model: Sod Cutters SC18H
- Type: Sod Cutters
- Engine Model: Honda GX160
- Engine Displacement: 9.9 in³
- Width: 25 in
- Cutting Width: 18 in
- Max Cutting Depth: 2.5 in
- Max Blade Speed: 1,225 rpm
- Drive System: A-section belt from engine to hydrostat that transfers power through enclosed lubricated gearcase; Wheels: gears and chain reduction to drive wheels; Blade: gears to blade eccentric shaft
- Transmission: Hydro-Gear #BDU-10S-127; 10cc pump
- Gearbox: 0.25" thick cast iron housing
- Engine Model: Honda GX160
- Engine Displacement: 9.9 in³
- Horsepower: 4.8 hp
- Fuel Capacity: 0.82 gal
- Weight: 380 lb
- Length: 52.5 in
- Width: 25 in
- Height: 35.5 in
- Front Tire(s): (2) 8 in vulcanized knob tread cast iron drive wheels
- Rear Tire(s): (1) 9 in x 3.5 in - 4 in caster wheel
- Blade Material: Heat-treated 10B38 boron steel
- Cutting Width: 18 in
- Max Cutting Depth: 2.5 in
- Max Blade Speed: 1,225 rpm
- Depth Adjustment: Locking lever releases to desired depth
- Drive System: A-section belt from engine to hydrostat that transfers power through enclosed lubricated gearcase; Wheels: gears and chain reduction to drive wheels; Blade: gears to blade eccentric shaft
- Transmission: Hydro-Gear #BDU-10S-127; 10cc pump
- Gearbox: 0.25" thick cast iron housing
- Hydraulic Oil Capacity: 2.1 qt
- Max Forward Speed: 4 mph
- Max Reverse Speed: 2 mph
