Starting from:
$14,040
Specifications
- Manufacturer: Wallenstein
- Model: Backhoes & Skid Diggers GX920
- Type: Diggers
- Digging Depth:: 9' 4" (284 cm)
- Engine HP Range (Tractor):: 45 - 120
- Engine HP Range (Skidsteer):: 45 - 120
- Required Hydraulic Flow:: 5 - 27 gpm (19 - 102 lpm)
- Stabilizer Width (Spread) :: 89" (226 cm)
- Main Boom Cylinder Diameter :: 3" (76 mm)
- Dipper Cylinder Diameter :: 2.5" (64 mm)
- Bucket Cylinder Diameter:: 2.5" (64 mm)
- Number Of Swing Cylinders:: 2
- Swing Cylinder Diameter:: 2.5" (64 mm)
- Stabilizer Cylinder Diameter:: 3" (76 mm)
- Reach From Swing Post :: 141" (358 cm)
- Includes Flow Divider:: Yes
- Bucket Rotation:: 180°
- Swing Arc:: 180°
- SAE* Dipper Boom Digging Force:: 3200 lbs (1451 kg)
- SAE* Bucket Digging Force:: 3925 lbs (1780 kg)
- Boom Lift Capacity:: 750 lbs (340 kg)
- Ground Clearance:: 10.5" (27 cm)
- Loading Height:: 89" (226 cm)
- Overall Operating Height (Fully Raised):: 135" (343 cm)
- Total Weight:: 791 lbs (359 kg)
- Transport Dimensions (LxWxH):: 81" x 43" x 92" (206 cm x 109 cm x 234 cm)
- Operating Pressure:: 2250 psi (15513 kPa)
- Mounting System:: Subframe, Skidsteer Universal Plate, PT302 (Cat I), PT322 (Cat II)
